E030401 Semi-auto Biochemistry Analyzer
E030401 Semi-auto Biochemistry Analyzer
●Based on the Linux operating system, the presenter in figures and diagrams contact surface, large screen real color liquid crystal display
●Touch screen operation, English input
●Adopt 32 bit high speed RISC processors, operating speed is up to 220,000,000 times per second .
●Optimal Optical Performance
Adopt imported concave grating as dispersive element，adjust wavelength continuously, good optical performance, long life time.
●Fire-new Biochemistry Management System
Based on the Linux operating system, the presenter in figures and diagrams contact surface, large screen real color liquid crystal display
Touch screen operation, English input, adopt 32 bit high speed RISC processors, operating speed is up to 220,000,000 times per second.
Build-in integrated biochemistry management software engine, can manage data and input patients material in English directly.
●Comprehensive measuring method and computing mode
Kinetics, End Point (Linear、Non-linear), Two-point, Absorbance, Single Wavelength, Double wavelength, Sample Blank;
●Perfect QC Method
With three different concentration QC test and multi-rule judgment function, auto statistic and draw L-J QC chart, can query and print QC chart and QC data.
●Powerful Database
Store over 200 item programme parameters, 500,000 measuring data and over 2 years’ three level QC data and QC chart, also can query and print at any time; with functions of data guide and educe.
●Practical Functions
1. With many kinds of jurisdiction cascade protection function.
2.Colorized graphical interfaces, input information of doctor and patient with touch screen of the instrument or mouse、keyboard, operation simple and direct-viewing.
3.Interface has real-time help and operation prompt functions.
4.Setup standard repeated measuring times, with auto repeated standard measuring and compute average value function.
5.Setup reference range according to different sex、age, more convenient to clinical reference.
6.Auto store、auto print, dynamically display response process curve.
Main Technical Parameters:
● Light source: halogen lamp
● Wavelength Range: 280～1000 nm
● Wavelength Accuracy: ±1 nm
● Range of absorbency: 0-3.0A
● Cross Contamination: <1%
● Colorimetric Cell: 10mm、32ul
● Temperature Control: 25℃、30℃、37℃ and Room Temperature
● Temperature Accuracy: ±0.1℃
● Processor: built-in high speed processor
● Storage: store over 200 test items and 500,000 test results.
● Display: high resolution colorized LCD display, dynamically display reaction curve.
● Print: Build-in 110mm high speed thermal sensitive printer, also can connect outside printer.
● Interface: Standard RS-232 interface、4 USB interfaces, Ethernet interface.
